CRW 250mm Industrial Axial Exhaust Fan with Gravity Louvers | Wall-Mounted High Efficiency Ventilation Fan 220-240V
Product Description:
The CRW HA-250M is a compact yet powerful 250mm axial plate fan ideal for commercial and industrial ventilation applications. Engineered with a gravity-operated shutter, this exhaust fan prevents reverse airflow and automatically seals when not in use—offering both performance and protection in one unit. Suitable for wall mounting, this unit is perfect for mechanical rooms, kitchens, workshops, warehouses, and other enclosed spaces requiring reliable air extraction.
Its efficient motor ensures energy savings while maintaining consistent airflow, making it a smart choice for continuous or intermittent ventilation needs.
Key Features:
-
✅ Reliable Airflow Performance: Air volume up to 590 m³/h—perfect for light industrial and commercial air extraction applications.
-
✅ Energy-Saving Design: Operates at just 30W on standard 220–240V / 50Hz, consuming minimal electricity.
-
✅ Built-in Gravity Grille: Automatic shutters open with airflow and close when off, protecting your space from dust, insects, and outdoor elements.
-
✅ Solid Construction & Speed: Sturdy plate housing and 1400 RPM motor ensure long-term durability with low vibration.
-
✅ Quick Wall-Mount Installation: Pre-drilled mounting flange fits easily into standard wall or duct openings.
Technical Specifications:
| Specification | Details |
|---|---|
| Model | HA-250M |
| Fan Size | 250mm (10 inches) |
| Voltage / Frequency | 220–240V / 50Hz |
| Power Consumption | 30W |
| Current Draw | 0.13 Amps |
| Rotational Speed | 1400 RPM |
| Airflow Capacity | 590 m³/h |
| Static Pressure | 30 Pa |
| Net Weight | 3.3 kg |
| Installation Type | Wall-mounted / Duct system |
| Grille Type | Gravity-operated louvers |
Customer reviews
-
Brand:Airtech-UK
-
Product Code:Plate Fan with Grille HA-250M
-
Weight:5kg
