Applications:
The Elitech CLD-100 Halogen Leak Detector may also be used to detect leaks in other systems and storage/ recovery containers. CLD-100 Halogen Leak Detector is an economic and practical halogen detection device with latest leaks detection technology.It is easy to operate, reliable in performance and compact in size.
Feature:
Detects all the refrigerants containing halogen.
Adusts sensitivity anytime to reach the best detection status automatically.
Imported chip to dispose signal, with accurate detecting result
Internal high precision and stabilivolt IC, ultra-low power consumption circuit design, more stable operation, long service life of batteries
Power voltage indication in bi-color
Exclusive designed sensor, hogh sensitivity and longer life
Technical parameters:
Operating temperature: 0 -52 (30°F to 125°F);
Response time : Instant
Detection mode:continuous, unlimited
Reset time:2-10s
Max sensitivity: 5 g/yr
Warm-time :about 6s
Battery life : about 20 hours
Power supply : 4 AAA batteries 6(VDC)
Conform to SAE_j1627 and EN14624 standards
Conform to RoHS
Specifications:
Overall size:53*50*175 mm
Probing rod length: 20cm;
Weight:150 g
Dimensions:22.9*6.5*6.5 (cm);
The Elitech CLD-100 Halogen Leak Detector may also be used to detect leaks in other systems and storage/ recovery containers. CLD-100 Halogen Leak Detector is an economic and practical halogen detection device with latest leaks detection technology.It is easy to operate, reliable in performance and compact in size.
Feature:
Detects all the refrigerants containing halogen.
Adusts sensitivity anytime to reach the best detection status automatically.
Imported chip to dispose signal, with accurate detecting result
Internal high precision and stabilivolt IC, ultra-low power consumption circuit design, more stable operation, long service life of batteries
Power voltage indication in bi-color
Exclusive designed sensor, hogh sensitivity and longer life
Technical parameters:
Operating temperature: 0 -52 (30°F to 125°F);
Response time : Instant
Detection mode:continuous, unlimited
Reset time:2-10s
Max sensitivity: 5 g/yr
Warm-time :about 6s
Battery life : about 20 hours
Power supply : 4 AAA batteries 6(VDC)
Conform to SAE_j1627 and EN14624 standards
Conform to RoHS
Specifications:
Overall size:53*50*175 mm
Probing rod length: 20cm;
Weight:150 g
Dimensions:22.9*6.5*6.5 (cm);
